Model: | MASONRY 500 |
CATALOG: | 9000-75 |
PART NUMBER | Masonry 500 |
20" electric block,brick, paver saw
The 500 series block saw accepts up to a 22" blade and is the only single arm design saw on the market. It is also the longest cutting tray and throw of any saw which allows for cutting blocks length wise without having to plunge cut. 9HP Honda motor with centrifugal clutch and a 5 HP, 220 volt electric motor round out the line up with this saw.
Smooth cutting and accuracy ensure problem free cuts for years to come and a lower center of gravity and wide stance make this saw practically impossible to tip even while transporting. The Masonry 500 will change your opinion of how a block saw is made. The vibration dampening centrifugal clutch makes this saw feel more like an electric saw that a gas powered unit. It's about time someone made a saw that was easy on the eyes, smooth as silk and vibration free. Bravo to IMER USA!
SPECIFICATIONS | |
Make | IMER |
Model | MASONRY 500 |
ARBOR SIZE | 1'' |
BLADE DIAMETER | 20'' to 22'' |
DIMENSIONS | 20''x16'' (Cutting Table) |
HEIGHT | 62'' |
HP | 5 |
LENGTH | 62''' |
MAXIMUM CUT DEPTH | 8'' |
MAXIMUM CUT LENGTH | 17''/ 22'' w/plunge cut |
NOISE LEVEL | 75 Dba |
PAN TRAY CAP | 9 gal. |
RPM | 2,100 (blade speed) |
TYPE | Electric |
VOLTAGE | 220V |
WATER PUMP FLOW | 3 gal./min. |
WEIGHT | 362 lbs |
WIDTH | 28'' |
ADDITIONAL COMMENTS |
The single arm frame design allows the passage of large or irregular materials. |
RECOMMENDED SAFETY USE |
Use eye protection at all times |
We Accept![]() |
To get a price |
Request a Quote via email, or call us at (718) 782-7887 and speak to a sales representative. Make sure you have the catalog number ready. |
